Product Summary
Features
(1)High output power : PO = 10 + 10 W@RL =2Ω,d = 10% ; PO = 20W@RL =4? ,d=1%.; (2)High reliability of the chip and package with addi-; (3)tional complete safety during operation thanks to; (4)protection against : OUTPUT DC AND AC SHORT CIRCUIT TO; (5)GROUND;OVERRATING CHIP TEMPERATURE;LOAD DUMP VOLTAGE SURGE;FORTUITOUS OPEN GROUND;VERY INDUCTIVE LOADS; (6)Flexibility in use :bridge or stereo booster ampli-fiers with or without boostrap and with programma-ble gain and bandwidth.; (7)Space and cost saving :very low number of external components, very simple mounting system with no electrical isolation between the package and the heatsink (one screw only).In addition, the circuit offersloudspeaker protection during short circuit for one wire to ground.
Diagrams
<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/20127213514860.jpg">
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TDA2005 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
 |
TDA2005R |
STMicroelectronics |
Audio Amplifiers Car-Audio Amplifier Class AB Specific |
Data Sheet |
|
|
||||||||||||
|
TDA2005S |
STMicroelectronics |
Audio Amplifiers 20W Bridge Amplifier |
Data Sheet |
Negotiable |
|
||||||||||||
|
TDA2005M |
STMicroelectronics |
Audio Amplifiers 20W Bridge Amplifier |
Data Sheet |
Negotiable |
|
||||||||||||
