Product Summary

The IXFK48N50 is a Power MOSFET. The applications of the device are DC-DC converters, Synchronous rectification, Battery chargers, Switched-mode and resonant-mode power supplies, DC choppers, Temperature and lighting controls.

Parametrics

IXFK48N50 absolute maximum ratings: 1)VDSS: 500 V; (2)VGS(th): 4 V; (3)IGSS: ±200 nA; (4)IDSS: 400 uA; (5)RDS(on): 0.12 Ω.

Features

IXFK48N50 features: (1)International standard packages; (2)Molding epoxies meet UL 94 V-0 flammability classification; (3)SOT-227B miniBLOC with aluminium nitride isolation; (4)Low RDS (on) HDMOSTM process; (5)Unclamped Inductive Switching (UIS) rated; (6)Fast intrinsic rectifier.

Diagrams

IXFK48N50 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
IXFK48N50
IXFK48N50

Ixys

MOSFET DIODE Id48 BVdass500

Data Sheet

Negotiable
IXFK48N50Q
IXFK48N50Q

Ixys

MOSFET 48 Amps 500V 0.1 Rds

Data Sheet

Negotiable
