ICM7555ID

ICM7555ID - NXP Semiconductors - General purpose CMOS timer

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.48~0.60 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 5000 :	0.60 / Piece
5001 ~ 10000 :	0.50 / Piece
10001 ~ 100000 :	0.48 / Piece

PartNumber:: ICM7555ID

Brand:: NXP - NXP | Pack: SOP | D/C: 13+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. chen's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-09-08

From Other Seller

Part Number:ICM7555ID
US $0.48 - 0.60
Quantity:

piece

Product Summary

The ICM7555 is a CMOS timer providing significantly improved performance over the standard NE/SE555 timer, while at the same time being a direct replacement for those devices in most applications. Improved parameters include low supply current, wide operating supply voltage range, low THRESHOLD, TRIGGER, and RESET currents, no crowbarring of the supply current during output transitions, higher frequency performance and no requirement to decouple CONTROL VOLTAGE for stable operation.
The ICM7555 is a stable controller capable of producing accurate time delays or frequencies.
In the one-shot mode, the pulse width of each circuit is precisely controlled by one external resistor and capacitor. For astable operation as an oscillator, the free-running frequency and the duty cycle are both accurately controlled by two external resistors and one capacitor. Unlike the bipolar 555 device, the CONTROL VOLTAGE terminal need not be decoupled with a capacitor. The TRIGGER and RESET inputs are active low. The output inverter can source or sink currents large enough to drive TTL loads or provide minimal offsets to drive CMOS loads

Features

Exact equivalent in most applications for NE/SE555
Low supply current: 80μA (typ)
Extremely low trigger, threshold, and reset currents: 20pA (typ)
High-speed operation: 500kHz guaranteed
Wide operating supply voltage range guaranteed 3 to 16V over full automotive temperatures
Normal reset function; no crowbarring of supply during output transition
Can be used with higher-impedance timing elements than the bipolar 555 for longer time constants
