Product Summary

The LS100C is a single output general purpose power supplier. Applications of the LS100C are :test & measurement, automated service, factory automation general purpose, led lighting & display.

Parametrics

LS100C absolute maximum ratings: (1)Input Frequency: 47 - 63Hz; (2)DC Input Voltage: 248 - 273VDC; (3)Inrush Current (230VAC, cold start): 2.2 / 1.2; (4)Leakage Current (230VAC 60Hz): <1mA; (5)Operating Humidity: 20 - 90% RH (non condensing).

Features

LS100C features: (1)High MTBF ; (2)High efficiency; (3)-25 to +70℃ operating temperature ; (4)Low derating above 50 ℃ (up to 70% load available at 70℃) ; (5)Curve B EMC.

Diagrams

LS100C pin connection
