Product Summary
The MAX232ACSE is a 5V-powered multichannel driver. Its applications include Portable Computers
Low-Power Modems, Interface Translation, Battery-Powered RS-232 Systems, Multidrop RS-232 Networks. It is especially useful in battery-powered systems, since their low-power shutdown mode reduces power dissipation to less than 5µW.
Parametrics
MAX232ACSE absolute maximum ratings: (1)(Voltages referenced to GND.VCC:-0.3V to +6V;V+ (Note 1) =(VCC - 0.3V) to +14V;V- (Note 1) =+0.3V to -14V; (2)Input Voltages:TIN ;-0.3V to (VCC - 0.3V);RIN=±30V;TOUT =±15V; (3)Output Voltages:TOUT=±15V;ROUT=-0.3V to (VCC + 0.3V); (4)Driver/Receiver Output Short Circuited to GND:Continuous; (5)Continuous Power Dissipation (TA = +70°C):16-Pin Narrow SO (derate 8.70mW/°C above +70°C) =696mW;16-Pin Wide SO (derate 9.52mW/°C above +70°C)=762mW; (6)Operating Temperature Ranges:MAX232ACSE=0°C to +70°C; (7)Storage Temperature Range :-65°C to +160°C; (8)Lead Temperature (soldering, 10s) :+300°C; (9)Soldering Temperature (reflow):+240°C.
Features
MAX232ACSE features: (1)Operate from Single +5V Power Supply; (2)Low-Power Receive Mode in Shutdown; (3)Meet All EIA/TIA-232E and V.28 Specifications; (4)Multiple Drivers and Receivers; (5)3-State Driver and Receiver Outputs; (6)Open-Line Detection.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MAX232ACSE |
Maxim Integrated Products |
RS-232 Interface IC |
Data Sheet |
Negotiable |
|
||||||||||||
|
MAX232ACSE+ |
Maxim Integrated Products |
RS-232 Interface IC 5V MultiCh RS-232 Driver/Receiver |
Data Sheet |
|
|
||||||||||||
|
MAX232ACSE+T |
Maxim Integrated Products |
RS-232 Interface IC 5V MultiCh RS-232 Driver/Receiver |
Data Sheet |
|
|
||||||||||||
 |
MAX232ACSE-T |
Maxim Integrated Products |
RS-232 Interface IC |
Data Sheet |
Negotiable |
|
||||||||||||
