Product Summary

This document contains a detailed description of the M68HC11 E series of 8-bit microcontroller units (MCUs). These MCUs all combine the M68HC11 central processor unit (CPU) with high-performance, on-chip peripherals.
The E series is comprised of many devices with various configurations of:
? Random-access memory (RAM)
? Read-only memory (ROM)
? Erasable programmable read-only memory (EPROM)
? Electrically erasable programmable read-only memory (EEPROM)
? Several low-voltage devices are also available.
With the exception of a few minor differences, the operation of all E-series MCUs is identical. A fully static design and high-density complementary metal-oxide semiconductor (HCMOS) fabrication process allow the E-series devices to operate at frequencies from 3 MHz to dc with very low power consumption.

Features

M68HC11 CPU
Power-saving stop and wait modes
Low-voltage devices available (3.0–5.5 Vdc)
0, 256, 512, or 768 bytes of on-chip RAM, data retained during standby
0, 12, or 20 Kbytes of on-chip ROM or EPROM
0, 512, or 2048 bytes of on-chip EEPROM with block protect for security
2048 bytes of EEPROM with selectable base address in the MC68HC811E2
Asynchronous non-return-to-zero (NRZ) serial communications interface (SCI)
Additional baud rates available on MC68HC(7)11E20
Synchronous serial peripheral interface (SPI)
8-channel, 8-bit analog-to-digital (A/D) converter
