Product Summary

The STM32F103C8T6 is a performance line, ARM-based 32-bit MCU with flash, USB, CAN, seven 16-bit timers. It incorporates the high-performance ARM Cortex-M3 32-bit RISC core operating at a 72 MHz frequency, high-speed embedded memories (Flash memory up to 128Kbytes and SRAM up to 20 Kbytes), and an extensive range of enhanced I/Os and pe ripherals connected to two APB buses. All devices offer two 12-bit ADCs, three general purpose 16 bit timers plus one PWM timer, as well as standard and advanced communication interfaces: up to two I2Cs and SPIs, three USARTs, an USB and a CAN.

Parametrics

STM32F103C8T6 absolute maximum ratings: (1)External 3.3V supply voltage: 4V; (2)input voltage on five V tolerant: 5.5V; (3)variations between different power pins: 50mV; (4)variations between all the different ground pins: 50mV.

Features

STM32F103C8T6 features: (1)Core: ARM 32-bit Cortex tm-M3 CPU:– 72 MHz, 90 DMIPS with 1.25 DMIPS/MHz;– Single-cycle multiplication and hardware division;– Nested interrupt controller with 43 maskable interrupt channels;– Interrupt processing (down to 6 CPU cycles) with tail chaining ; (2)Memories:– 32-to-128 Kbytes of Flash memory;– 6-to-20 Kbytes of SRAM ; (3)Clock, reset and supply management:– 2.0 to 3.6 V application supply and I/Os ;– POR, PDR, and programmable voltage detector (PVD);– 4-to-16 MHz quartz oscillator ;– Internal 8 MHz factory-trimmed RC;– Internal 32 kHz RC;– PLL for CPU clock;– Dedicated 32 kHz oscillator for RTC with calibration.

Diagrams

STM32F103C8T6 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
STM32F103C8T6
STM32F103C8T6
STMicroelectronics
ARM Microcontrollers (MCU) 32BIT Cortex M3 64KB 20KB RAM 2X12 ADC
Data Sheet
0-1: $3.43
1-10: $3.08
10-100: $2.53
100-250: $2.33
STM32F103C8T6TR
STM32F103C8T6TR
STMicroelectronics
ARM Microcontrollers (MCU) 32BIT Cortex M3 USB 7 TIMERS 2 ADCS CAN
Data Sheet
0-1785: $1.85
1785-2000: $1.78
2000-2400: $1.78
