Product Summary

XC4000 Series devices are implemented with a regular,flexible, programmable architecture of Configurable Logic Blocks (CLBs), interconnected by a powerful hierarchy of
versatile routing resources, and surrounded by a perimeter of programmable Input/Output Blocks (IOBs). They have generous routing resources to accommodate the most complex interconnect patterns. The devices are customized by loading configuration data into internal memory cells. The FPGA can either actively read its configuration data from an external serial or byte-parallel PROM (master modes), or the configuration data can be written into the FPGA from an external device
(slave and peripheral modes).
XC4000 Series FPGAs are supported by powerful and sophisticated software, covering every aspect of design from schematic or behavioral entry, floor planning, simula-tion, automatic block placement and routing of intercon-nects, to the creation, downloading, and readback of the
configuration bit stream .
